| Model | MW7225-MS |
| Module | |
| Pixel Pitch | P2.5 |
| Module Resolution (W × H) | 96 × 48 |
| Module Dimensions (mm) | 240 × 120 × 5 |
| Central arc angle | ≤120° |
| Cabinet | |
| Processing Image | |
| Single Pixel Brightness Correction | Support |
| Single Pixel Color Correction | Support |
| Brightness (nits) | 600 |
| Color Temperature (K) | 3000 to 9000 adjustable |
| Viewing Angle (H/V) | 160°/140° |
| Center distance deviation of LED | < 3% |
| Brightness Uniformity | ≥ 97% |
| Color Uniformity (Cx, Cy) | ± 0.003 |
| Contrast Ratio | 4000:1 |
| Processing performance | |
| Pixel Density (pitch/m²) | 160000 |
| Surface Evenness (mm) | ≤ 0.2 |
| Grayscale | 14 bit |
| Scanning Mode | 24 S |
| Drive Mode | Constant current driving |
| Frame Frequency (Hz) | 50/60 |
| Refresh Rate (Hz) | 3840 |
| Electrical | |
| Power Supply | AC 200 to 240 |
| Average Power Consumption (W/m²) | 150 |
| Max. Power Consumption (W/m²) | 550 |
| General | |
| Maintenance Mode | Front/rear |
| Ingress Protection | IP30 |
| Weight (kg/pcs) | 0.2 |
| Operating Temperature | ‑10°C to 40°C |
| Operating Humidity | 10% to 55% RH, non‑condensing |
| Storage Temperature | ‑20°C to 60°C |
| Storage Humidity | 10% to 55% RH, non‑condensing |
| LED Lifetime (h) | 50000 |
