| LED Type | SMD2121 | |
| Pixel Pitch | 2.5mm | |
| Module Resolution（W×H） | 128X64=8192 Pixels | |
| HUB | HUB75 | |
| Module Dimension（ W×H×D） | 320mm×160mm×16.6mm | |
| Module Weight | 0.38±0.02kg | |
| Single-dot Brightness Calibration | Support | |
| White Balance Brightness | ≥500 ~ 800 CD/m2 | |
| Standard Color Temperature | 6500K (1000K～ 9500K Adjustable) | |
| Beam Angle（Hor/Ver°） | 140°/140° | |
| Contrast Ratio | 5000:1 | |
| Input Power <Max> | 488W/m2 | |
| Input Power <Typical> | 163W/m2 | |
| Power Supply Input Voltage | AC90～ 132V/ AC186～ 264V， Frequency 47-63（Hz） |
|
| Frame Changing Frequency | 60Hz | |
| Drive Mode | Constant Current Drive / 32 Scan | |
| Refresh Rate | 3840Hz | |
| Processing Depth | 12~14 Bit | |
| Video Support | 2K HD, 4K UHD | |
| Life Typical Value (HRS) | 100000H | |
| Working Temperature/ Humidity Range （℃/RH） |
-20℃–45℃ / 10%-80%RH | |
| Storage Temperature / Humidity Range （℃/RH） |
-10℃–50℃ / 10%-70%RH |
