| LED Type | SMD1515 | |
| Pixel Pitch | 2mm | |
| Module Resolution（W×H） | 160x80=12800 Pixels | |
| HUB | HUB75 | |
| Module Dimension( W×H×D) | 320mm×160mm×16.6mm | |
| Module Weight | 0.45±0.02kg | |
| Single-dot Brightness Calibration | Support | |
| White Balance Brightness | ≥500 CD/m2 | |
| Standard Color Temperature | 6500K (1000K～ 9500K Adjustable) | |
| Beam Angle（Hor/Ver°） | 140°/140° | |
| Contrast Ratio | 5000:1 | |
| Input Power <Max> | 488W/m2 | |
| Input Power <Typical> | 163W/m2 | |
| Power Supply Input Voltage | AC90～ 132V/ AC186～ 264V， Frequency 47~63（Hz） |
|
| Frame Changing Frequency | 60Hz | |
| Drive Mode | Constant Current Drive / 40 Scan | |
| Refresh Rate | 3840Hz | |
| Processing Depth | 12~14 Bit | |
| Video Support | 2K HD, 4K UHD | |
| Life Typical Value (HRS) | 100000H | |
| Working Temperature/ Humidity Range （℃/RH） |
-20℃~50℃ / 10%~80%RH (No Condensation) |
|
| Storage Temperature / Humidity Range （℃/RH） |
-10℃~30℃ / 10%~70%RH (No Condensation) |
